Functional parameters:

Printing fonts

High definition spray print font or dot matrix font; entity and dot matrix font can be mixed edited;

Number of Printing Lines

The number of rows can be chosen within 12.7mm, and the font with the height of 1mm to 12mm can be sprayed.

Special functions

Flash spray, strong spray, movablebar code, movabletwo-dimensional code, etc.

Spray Printing Content

Text, counter (changeable), time and date (changeable), bar code (changeable), two-dimensional code (changeable), picture, etc.

Machine System

Operating System of Thermal Foaming Printer

Spray Printing Speed

The maximum printing speed can reach 120 meters per minute, and the printing speed does not change with the increase of the number of rows; the maximum resolution is 600 DPI

Operating interface

Humanized operation of the english interface, including the english font; English menu;

Easy to operate: canachieve the effect of operation

Spray Printing Material

It can be sprayed on metal, plastic, wood, aluminium platinum, carton, building materials, electronic products and other surfaces.

Ink Consumables

Use environmentally friendly fast-drying ink or water-based ink, without adding solvents, pollution-free, without external air source or built-in air pump

Communication Interface

Through the USB interface,the U disk uploads the required picture LOGO to the machine, upgrade program and so on.

Contact switch, pedal switch, sensor interface and synchronizer interface.It can set three induction trigger signals in thesystem: sensor induction, synchronizer induction, sensor and synchronizer mixing.
